| Local Name | Zenfone 3 Max ZC553KL |
| Technology | GSM / HSPA / LTE |
| 4G Bands | 1, 2, 3, 5, 7, 8, 20 - Global | 1, 2, 3, 5, 6, 7, 8, 18, 19, 26, 28, 38, 41 - Taiwan, Brazil | 1, 3, 5, 8, 40 - India |
| 3G Bands | HSDPA 850 / 900 / 1900 / 2100 - Global | HSDPA 850 / 900 / 1900 / 2100 / 800 - Taiwan, Brazil | HSDPA 850 / 900 / 2100 - India |
| 2G Bands | GSM 850 / 900 / 1800 / 1900 - SIM 1 & SIM 2 |
| Speed | HSPA 42.2/5.76 Mbps, LTE Cat4 150/50 Mbps |
| Announced | 2016, November |
| Status | Available. Released 2016, November |
| Dimensions | 151.4 x 76.2 x 8.3 mm (5.96 x 3.00 x 0.33 in) |
| Weight | 175 g (6.17 oz) |
| Build | Glass front, aluminum back, aluminum frame |
| SIM | Hybrid Dual SIM (Nano-SIM, dual stand-by) |
| Display Type | IPS LCD capacitive touchscreen, 16M colors |
| Screen Size | 5.5 inches, 83.4 cm2 (~72.3% screen-to-body ratio) |
| Resolution | 1080 x 1920 pixels, 16:9 ratio (~401 ppi density) |
| Protection | Oleophobic coating |
| OS | Android 6.0.1 (Marshmallow), upgradable to Android 8.1 (Oreo); ZenUI 4 |
| Chipset | Qualcomm MSM8937 Snapdragon 430 (28 nm) |
| CPU | Octa-core 1.4 GHz Cortex-A53 |
| GPU | Adreno 505 |
| Card Slot | microSDXC (uses shared SIM slot) |
| Internal Memory | 32GB 2GB RAM, 32GB 3GB RAM, 32GB 4GB RAM | eMMC 5.1 |
| Camera Features | Dual-LED dual-tone flash, panorama, HDR |
| Loudspeaker | Yes |
| 3.5mm Jack | Yes |
| WLAN | Wi-Fi 802.11 b/g/n, Wi-Fi Direct, hotspot |
| Bluetooth | 4.1, A2DP, LE |
| GPS | Yes, with A-GPS, GLONASS, BDS |
| Radio | FM radio |
| USB | microUSB 2.0, USB On-The-Go |
| Sensors | Fingerprint (rear-mounted), accelerometer, gyro, proximity, compass |
| Battery | Non-removable Li-Ion 4100 mAh battery |
| Stand By | Up to 912 h (3G) |
| Talk Time | Up to 17 h (3G) |
| Music Play | Up to 72 h |
| Colors | Titanium Gray, Glacier Silver, Rose Pink, Sand Gold |
