| Local Name | Zenfone 4 Max ZC520KL |
| Technology | GSM / HSPA / LTE |
| 4G Bands | 1, 3, 5, 7, 8, 20, 40 |
| 3G Bands | HSDPA 850 / 900 / 2100 |
| 2G Bands | GSM 850 / 900 / 1800 / 1900 - SIM 1 & SIM 2 |
| Speed | HSPA 42.2/5.76 Mbps, LTE Cat4 150/50 Mbps |
| Announced | 2017, August |
| Status | Available. Released 2017, October |
| Dimensions | 150.5 x 73.3 x 8.8 mm (5.93 x 2.89 x 0.35 in) |
| Weight | 156 g (5.50 oz) |
| SIM | Dual SIM (Micro-SIM/Nano-SIM, dual stand-by) |
| Display Type | Li-Po 4100 mAh, non-removable |
| Screen Size | 5.2 inches, 74.5 cm2 (~67.6% screen-to-body ratio) |
| Resolution | 720 x 1280 pixels, 16:9 ratio (~282 ppi density) |
| OS | Android 7 (Nougat), upgradable to Android 8 (Oreo), ZenUI 4 |
| Chipset | Qualcomm MSM8917 Snapdragon 425 (28 nm) |
| CPU | Quad-core 1.4 GHz Cortex-A53 |
| GPU | Adreno 308 |
| Card Slot | microSDXC (dedicated slot) |
| Internal Memory | 16GB 2GB RAM, 32GB 3GB RAM | eMMC 5.1 |
| Camera Features | LED flash |
| Video | 1080p@30fps |
| Loudspeaker | Yes |
| 3.5mm Jack | Yes |
| WLAN | Wi-Fi 802.11 b/g/n, Wi-Fi Direct, hotspot |
| Bluetooth | 4.1, A2DP, LE |
| GPS | Yes, with A-GPS, GLONASS |
| NFC | No |
| Radio | FM radio |
| USB | microUSB 2.0, USB On-The-Go |
| Sensors | Fingerprint (front-mounted), accelerometer, gyro, proximity, compass |
| Colors | Black, Gold, Silver |
