| Local Name | G5 |
| Additional Information | Versions: H850 (Europe); LG G5 Speed H858 (Taiwan); VS987 (Verizon); H820 (AT&T); LS992 (Sprint); H830 (T-Mobile); US992 (US Cellular); Vodafone Also known as LG G5 Dual H860N with dual-SIM card slots |
| Technology | GSM / CDMA / HSPA / LTE |
| 4G Bands | LTE band 1(2100), 2(1900), 3(1800), 4(1700/2100), 5(850), 7(2600), 8(900), 12(700), 17(700), 20(800), 28(700), 38(2600), 40(2300) - H850 | LTE band 1(2100), 2(1900), 3(1800), 4(1700/2100), 5(850), 7(2600), 12(700), 20(800) - H830 | LTE band 1(2100), 2(1900), 3(1800), 4(1700/2100), 5(850), 7(2600), 1 |
| 3G Bands | HSDPA 850 / 900 / 1900 / 2100 - H850 | HSDPA 850 / 1700(AWS) / 1900 / 2100 - H830, US992 | HSDPA 850 / 1900 / 2100 - H820CDMA2000 1xEV-DO - VS987 | HSDPA 850 / 900 / 1700(AWS) / 1900 / 2100 - H860N |
| 2G Bands | GSM 850 / 900 / 1800 / 1900 - SIM 1 & SIM 2 (dual-SIM model only) | CDMA 800 / 1900 - VS987, US992 |
| Speed | HSPA 42.2/5.76 Mbps, LTE-A Cat6 300/50 Mbps or LTE-A Cat9 (3CA) 450/50 Mbps, EV-DO Rev.A 3.1 Mbps |
| GPRS | Yes |
| EDGE | Yes |
| Announced | 2016, February |
| Status | Available. Released 2016, April |
| Dimensions | 149.4 x 73.9 x 7.7 mm (5.88 x 2.91 x 0.30 in) |
| Weight | 159 g (5.61 oz) |
| Build | Aluminum body |
| SIM | Single SIM (Nano-SIM) or Hybrid Dual SIM (Nano-SIM, dual stand-by) |
| Display Type | IPS LCD capacitive touchscreen, 16M colors |
| Screen Size | 5.3 inches, 77.4 cm2 (~70.1% screen-to-body ratio) |
| Resolution | 1440 x 2560 pixels, 16:9 ratio (~554 ppi density) |
| Protection | Corning Gorilla Glass 4 | Always-on display |
| OS | Android 6.0.1 (Marshmallow), upgradable to Android 8.0 (Oreo); LG UX 5 UI |
| Chipset | Qualcomm MSM8996 Snapdragon 820 (14 nm) |
| CPU | Quad-core (2x2.15 GHz Kryo & 2x1.6 GHz Kryo) |
| GPU | Adreno 530 |
| Card Slot | microSD, up to 512 GB (uses SIM 2 slot) - dual SIM model only |
| Internal Memory | 32 GB, 4 GB RAM |
| Camera Features | LED flash, panorama, HDR |
| Video | 1080p@30fps |
| Loudspeaker | Yes |
| 3.5mm Jack | Yes |
| Sound | 24-bit/192kHz audio - Active noise cancellation with dedicated mic |
| WLAN | Wi-Fi 802.11 a/b/g/n/ac, dual-band, Wi-Fi Direct, DLNA, hotspot |
| Bluetooth | 4.2, A2DP, LE, aptX HD |
| GPS | Yes, with A-GPS, GLONASS, BDS |
| NFC | Yes |
| Infrared Port | Yes |
| Radio | FM radio |
| USB | 3.0, Type-C 1.0 reversible connector, USB On-The-Go |
| Sensors | Fingerprint (rear-mounted), accelerometer, gyro, proximity, compass, barometer, color spectrum |
| Battery | Removable Li-Ion 2800 mAh battery |
| Stand By | Up to 400 h (3G) |
| Talk Time | Up to 20 h (3G) |
| Colors | Silver, Titan, Gold, Pink |
| SAR EU | 0.52 W/kg (head) 1.24 W/kg (body) |
