Moto G5 Plus

Additional Information	Versions: XT1684 (Single SIM); XT1685 (Dual SIM); XT1687 (USA); XT1686 (India)
Dimensions	150.2 x 74 x 7.7 mm (5.91 x 2.91 x 0.30 in)
Weight	155 g (5.47 oz)
Technology	GSM / CDMA / HSPA / EVDO / LTE
Resolution	1080 x 1920 pixels, 16:9 ratio (~424 ppi density)
Internal Memory	32GB 2GB RAM, 32GB 3GB RAM, 64GB 4GB RAM \| eMMC 5.1
CPU	Octa-core 2.0 GHz Cortex-A53
Camera Features	Dual-LED dual-tone flash, panorama

(Specifications are not translated in your language or for your country. Currently using the default language.)

Product Status: Trading

Moderators:

Presented by:

2017/04/23

Updated by:

2020/05/22

Local Name	Moto G5 Plus
Additional Information	Versions: XT1684 (Single SIM); XT1685 (Dual SIM); XT1687 (USA); XT1686 (India)
Technology	GSM / CDMA / HSPA / EVDO / LTE
4G Bands	1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 25, 26, 38, 41, 66 - XT1687 (USA) \| 1, 3, 5, 7, 8, 19, 20, 28, 38, 40, 41 - XT1684, XT1685 \| 1, 3, 5, 8, 40 - XT1686
3G Bands	HSDPA 850 / 900 / 1700(AWS) / 1900 / 2100 - XT1687 (USA) \| CDMA2000 1xEV-DO - XT1687 (USA) \| HSDPA 850 / 900 / 1900 / 2100 - XT1684, XT1685 \| HSDPA 850 / 900 / 2100 - XT1686
2G Bands	GSM 850 / 900 / 1800 / 1900 - SIM 1 & SIM 2 (dual-SIM model only) \| CDMA 800 / 1900 - XT1687 (USA)
Speed	HSPA 42.2/5.76 Mbps, LTE-A (2CA) Cat6 300/50 Mbps, EV-DO Rev.A 3.1 Mbps
Announced	2017, February
Status	Available. Released 2017, April
Dimensions	150.2 x 74 x 7.7 mm (5.91 x 2.91 x 0.30 in)
Weight	155 g (5.47 oz)
Build	Glass front (Gorilla Glass 3), aluminum back, plastic frame
SIM	Single SIM (Nano-SIM) or Dual SIM (Nano-SIM, dual stand-by)
Body	Splash and dust resistant
Display Type	IPS LCD capacitive touchscreen, 16M colors
Screen Size	5.2 inches, 74.5 cm2 (~67.1% screen-to-body ratio)
Resolution	1080 x 1920 pixels, 16:9 ratio (~424 ppi density)
Protection	Corning Gorilla Glass 3
OS	Android 7.0 (Nougat), upgradable to Android 8.1 (Oreo)
Chipset	Qualcomm MSM8953 Snapdragon 625 (14 nm)
CPU	Octa-core 2.0 GHz Cortex-A53
GPU	Adreno 506
Card Slot	microSDXC (dedicated slot)
Internal Memory	32GB 2GB RAM, 32GB 3GB RAM, 64GB 4GB RAM \| eMMC 5.1
Camera Features	Dual-LED dual-tone flash, panorama
Video	1080p@30fps, 480p@120fps
Loudspeaker	Yes
3.5mm Jack	Yes
WLAN	Wi-Fi 802.11 a/b/g/n, dual-band, Wi-Fi Direct, hotspot
Bluetooth	4.2, A2DP, LE, EDR, aptX
GPS	Yes, with A-GPS, GLONASS
NFC	Yes (market dependent)
Radio	FM radio
USB	microUSB 2.0, USB On-The-Go
Sensors	Fingerprint (front-mounted), accelerometer, gyro, proximity, compass (USA model only)
Battery	Non-removable Li-Ion 3000 mAh battery
Colors	Lunar Grey, Fine Gold
SAR EU	0.30 W/kg (head) 1.24 W/kg (body)
