| Local Name | Eluga Ray 500 |
| Technology | GSM / HSPA / LTE |
| 4G Bands | 3, 5, 40 |
| 3G Bands | HSDPA 900 / 2100 |
| 2G Bands | GSM 850 / 900 / 1800 / 1900 - SIM 1 & SIM 2 |
| Speed | HSPA, LTE |
| Announced | 2017, September |
| Status | Available. Released 2017, September |
| Dimensions | 144.3 x 71.3 x 9.2 mm (5.68 x 2.81 x 0.36 in) |
| Weight | 163 g (5.75 oz) |
| SIM | Hybrid Dual SIM (Nano-SIM, dual stand-by) |
| Display Type | Li-Ion 4000 mAh, non-removable |
| Screen Size | 5.0 inches, 68.9 cm2 (~67.0% screen-to-body ratio) |
| Resolution | 720 x 1280 pixels, 16:9 ratio (~294 ppi density) |
| OS | Android 7 (Nougat) |
| Chipset | Mediatek MT6737 (28 nm) |
| CPU | Quad-core 1.25 GHz Cortex-A53 |
| GPU | Mali-T720MP1 |
| Card Slot | microSDXC (uses shared SIM slot) |
| Internal Memory | 32GB 3GB RAM | eMMC 5.0 |
| Camera Features | HDR |
| Loudspeaker | Yes |
| 3.5mm Jack | Yes |
| WLAN | Wi-Fi 802.11 b/g/n, Wi-Fi Direct |
| Bluetooth | 4.0, A2DP |
| NFC | No |
| Infrared Port | Yes |
| Radio | FM radio |
| USB | microUSB 2.0, OTG |
| Sensors | Fingerprint (front-mounted), accelerometer, proximity |
| Colors | Champagne gold, Mocha gold, Marine Blue |
