| Local Name | Galaxy Note8 |
| Additional Information | Versions: N950F (Single SIM: Europe, Australia); N950FD (Global Dual SIM: Europe, LATAM, Brazil; Australia); N950U/U1 (USA); N950W (Canada); N9500 (China); N950N (South Korea) Also known as Samsung Galaxy Note8 Duos with Dual SIM card slots. |
| Technology | GSM / HSPA / LTE |
| 4G Bands | LTE band 1(2100), 2(1900), 3(1800), 4(1700/2100), 5(850), 7(2600), 8(900), 12(700), 13(700), 17(700), 18(800), 19(800), 20(800), 25(1900), 26(850), 28(700), 32(1500), 38(2600), 39(1900), 40(2300), 41(2500), 66(1700/2100) |
| 3G Bands | HSDPA 850 / 900 / 1700(AWS) / 1900 / 2100 |
| 2G Bands | GSM 850 / 900 / 1800 / 1900 - SIM 1 & SIM 2 (dual-SIM model only) |
| Speed | HSPA 42.2/5.76 Mbps, LTE-A (5CA) Cat16 1024/150 Mbps |
| Announced | 2017, August |
| Status | Available. Released 2017, September |
| Dimensions | 162.5 x 74.8 x 8.6 mm (6.40 x 2.94 x 0.34 in) |
| Weight | 195 g (6.88 oz) |
| Build | Front/back glass (Gorilla Glass 5), aluminum frame |
| SIM | Single SIM (Nano-SIM) or Hybrid Dual SIM (Nano-SIM, dual stand-by) |
| Body | Samsung Pay (Visa, MasterCard certified) IP68 dust/water resistant (up to 1.5m for 30 mins) Stylus |
| Display Type | Super AMOLED capacitive touchscreen, 16M colors |
| Screen Size | 6.3 inches, 101.1 cm2 (~83.2% screen-to-body ratio) |
| Resolution | 1440 x 2960 pixels, 18.5:9 ratio (~521 ppi density) |
| Protection | Corning Gorilla Glass 5 | HDR10 3D Touch (home button only) Always-on display |
| OS | Android 7.1.1 (Nougat), upgradable to Android 9.0 (Pie) |
| Chipset | Exynos 8895 (10 nm) - EMEAQualcomm MSM8998 Snapdragon 835 (10 nm) - USA & China |
| CPU | Octa-core (4x2.3 GHz Mongoose M2 & 4x1.7 GHz Cortex-A53) - EMEAOcta-core (4x2.35 GHz Kryo & 4x1.9 GHz Kryo) - USA & China |
| GPU | Mali-G71 MP20 - EMEAAdreno 540 - USA & China |
| Card Slot | microSD, up to 1 TB (uses shared SIM slot) - dual SIM model only |
| Internal Memory | 64GB 6GB RAM, 128GB 6GB RAM, 256GB 6GB RAM |
| Camera Features | Dual video call, Auto-HDR |
| Video | 1440p@30fps |
| Loudspeaker | Yes |
| 3.5mm Jack | Yes |
| Sound | 32-bit/384kHz audio Active noise cancellation with dedicated mic |
| WLAN | Wi-Fi 802.11 a/b/g/n/ac, dual-band, Wi-Fi Direct, hotspot |
| Bluetooth | 5.0, A2DP, LE, aptX |
| GPS | Yes, with A-GPS, GLONASS, BDS, GALILEO |
| NFC | Yes |
| Radio | No |
| USB | 3.1, Type-C 1.0 reversible connector |
| Sensors | Iris scanner, fingerprint (rear-mounted), accelerometer, gyro, proximity, compass, barometer, heart rate, SpO2 |
| Features Summary | Samsung DeX (desktop experience support), ANT+, Bixby natural language commands and dictation |
| Battery | Non-removable Li-Ion 3300 mAh battery |
| Talk Time | Up to 22 h (3G) |
| Music Play | Up to 74 h |
| Colors | Midnight Black, Maple Gold, Orchid Gray, Deep Sea Blue, Star Pink (Taiwan only) |
