| Local Name | Galaxy On5 |
| Additional Information | T-Mobile version with 5 MP rear camera and 2 MP front camera |
| Technology | GSM / HSPA / LTE |
| 4G Bands | LTE band 1(2100), 3(1800), 5(850), 8(900), 20(800), 40(2300) | LTE band 2(1900), 4(1700/2100), 12(700) - T-Mobile |
| 3G Bands | HSDPA 850 / 900 / 1900 / 2100 | HSDPA 850 / 1700(AWS) / 1900 - T-Mobile |
| 2G Bands | GSM 850 / 900 / 1800 / 1900 - SIM 1 & SIM 2 |
| Speed | HSPA, LTE Cat4 150/50 Mbps |
| GPRS | Yes |
| EDGE | Yes |
| Announced | 2015, October |
| Status | Available. Released 2015, November |
| Dimensions | 142.3 x 72.1 x 8.5 mm (5.60 x 2.84 x 0.33 in) |
| Weight | 149 g (5.26 oz) |
| Build | Plastic body |
| SIM | Dual SIM (Micro-SIM, dual stand-by) |
| Display Type | TFT capacitive touchscreen, 16M colors |
| Screen Size | 5.0 inches, 71.8 cm2 (~70.0% screen-to-body ratio) |
| Resolution | 720 x 1280 pixels, 16:9 ratio (~288 ppi density) |
| Mulitouch | Yes |
| OS | Android 5.1 (Lollipop)Android 6.0 (Marshmallow) - T-Mobile |
| Chipset | Exynos 3475 Quad |
| CPU | Quad-core 1.3 GHz Cortex-A7 |
| GPU | Mali-T720 |
| Card Slot | microSD, up to 256 GB (dedicated slot) |
| Internal Memory | 8 GB, 1.5 GB RAM |
| Primary Camera | 8 MP, f/2.2, autofocus, LED flash |
| Camera Features | Geo-tagging, touch focus, face detection |
| Video | 1080p@30fps |
| Secondary Camera | 5 MP, f/2.2 |
| Alert Types | Vibration; MP3, WAV ringtones |
| Loudspeaker | Yes |
| 3.5mm Jack | Yes |
| WLAN | Wi-Fi 802.11 b/g/n, Wi-Fi Direct, hotspot |
| Bluetooth | 4.1, A2DP |
| GPS | Yes, with A-GPS, GLONASS |
| Radio | FM radio |
| USB | microUSB 2.0 |
| Sensors | Accelerometer, proximity |
| Messaging | SMS(threaded view), MMS, Email, Push Email, IM |
| Browser | HTML5 |
| Features Summary | MP4/H.264 player, MP3/WAV/eAAC+ player, Photo/video editor, Document viewer |
| Battery | Removable Li-Ion 2600 mAh battery |
| Talk Time | Up to 15 h (3G) |
| Music Play | Up to 49 h |
| Colors | White, Black |
| SAR EU | 0.40 W/kg (head) 0.31 W/kg (body) |
