| Local Name | Galaxy S5 Active |
| Additional Information | Also known as Samsung Galaxy S5 Active SM-G870A |
| Technology | GSM / HSPA / LTE |
| 4G Bands | LTE band 1(2100), 2(1900), 3(1800), 4(1700/2100), 5(850), 7(2600), 17(700) - AT&T | LTE band 1(2100), 2(1900), 3(1800), 4(1700/2100), 5(850), 7(2600), 17(700), 29(700) - Bell |
| 3G Bands | HSDPA 850 / 1900 / 2100 - AT&T, Bell |
| 2G Bands | GSM 850 / 900 / 1800 / 1900 - all versions |
| Speed | HSPA 42.2/11.5 Mbps, LTE Cat4 150/50 Mbps |
| GPRS | Class 33 |
| EDGE | Class 33 |
| Announced | 2014, May |
| Status | Available. Released 2014, May |
| Dimensions | 145.3 x 73.4 x 8.9 mm (5.72 x 2.89 x 0.35 in) |
| Weight | 170.1 g (6.00 oz) |
| SIM | Micro-SIM |
| Body | IP67 certified - dust and water resistant up to 1 meter and 30 minutes - MIL-STD-810G certified - salt, dust, humidity, rain, vibration, solar radiation, transport and thermal shock resistant |
| Display Type | Super AMOLED capacitive touchscreen, 16M colors |
| Screen Size | 5.1 inches (~67.2% screen-to-body ratio) |
| Resolution | 1080 x 1920 pixels (~432 ppi pixel density) |
| Mulitouch | Yes |
| Protection | Corning Gorilla Glass 3 | TouchWiz UI |
| OS | Android OS, v4.4.2 (KitKat), upgradable to v5.0 (Lollipop) |
| Chipset | Qualcomm Snapdragon 801 |
| CPU | Quad-core 2.5 GHz Krait 400 |
| GPU | Adreno 330 |
| Card Slot | microSD, up to 128 GB |
| Internal Memory | 16 GB (11.2 GB user available), 2 GB RAM |
| Primary Camera | 16 MP, 3456 x 4608 pixels, autofocus, LED flash |
| Camera Features | Simultaneous HD video and image recording, geo-tagging, touch focus, face/smile detection, HDR, Aqua mode |
| Video | 2160p@30fps, 1080p@30fps |
| Secondary Camera | 2 MP, 1080p@30fps |
| Alert Types | Vibration; MP3, WAV ringtones |
| Loudspeaker | Yes |
| 3.5mm Jack | Yes |
| WLAN | Wi-Fi 802.11 a/b/g/n/ac, dual-band, Wi-Fi Direct, hotspot |
| Bluetooth | v4.0, A2DP, EDR, LE, apt-X |
| GPS | Yes, with A-GPS, GLONASS |
| NFC | Yes |
| Radio | No |
| USB | microUSB v2.0, USB Host |
| Sensors | Accelerometer, gyro, proximity, compass, heart rate |
| Messaging | SMS(threaded view), MMS, Email, Push Mail, IM |
| Browser | HTML5 |
| Java | No |
| Features Summary | Active noise cancellation with dedicated mic, HDMI port, MP4/DivX/XviD/WMV/H.264 player, MP3/WAV/eAAC+/AC3/FLAC player, Photo/video editor, Document viewer |
| Battery | Li-Ion 2800 mAh battery |
| Stand By | Up to 480 h |
| Talk Time | Up to 29 h |
| Colors | Camo Green, Titanium Grey, Ruby Red |
| SAR US | 0.92 W/kg (head) 1.48 W/kg (body) |
| SAR EU | 0.67 W/kg (head) 0.45 W/kg (body) |
