| Local Name | Max XL |
| Additional Information | For Boost/Virgin Mobile Also known as ZTE Blade X Max for Sprint/Cricket |
| Technology | GSM / HSPA / LTE |
| 4G Bands | LTE (unspecified) |
| 3G Bands | HSDPA 850 / 1700(AWS) / 1900 |
| 2G Bands | GSM 850 / 900 / 1800 / 1900 |
| Speed | HSPA 42.2/5.76 Mbps, LTE-A (2CA) |
| GPRS | Yes |
| EDGE | Yes |
| Announced | 2017, April |
| Status | Available. Released 2017, April |
| Dimensions | 165.1 x 83.8 x 9.4 mm (6.5 x 3.30 x 0.37 in) |
| Weight | 180 g (6.35 oz) |
| SIM | Nano-SIM |
| Display Type | IPS LCD capacitive touchscreen, 16M colors |
| Screen Size | 6.0 inches, 99.2 cm2 (~71.7% screen-to-body ratio) |
| Resolution | 1080 x 1920 pixels, 16:9 ratio (~367 ppi density) |
| Protection | Corning Gorilla Glass (unspecified version) |
| OS | Android 7.1.1 (Nougat) |
| Chipset | Qualcomm MSM8940 Snapdragon 435 (28 nm) |
| CPU | Octa-core 1.4 GHz Cortex-A53 |
| GPU | Adreno 505 |
| Card Slot | microSD, up to 256 GB |
| Internal Memory | 32 GB, 2 GB RAM (Sprint) or 16 GB, 2 GB RAM |
| Camera Features | LED flash, HDR, panorama |
| Loudspeaker | Yes |
| 3.5mm Jack | Yes |
| Sound | Active noise cancellation with dedicated mic |
| WLAN | Wi-Fi 802.11 a/b/g/n, WiFi Direct, hotspot |
| Bluetooth | 4.2, A2DP, LE |
| GPS | Yes, with A-GPS |
| Radio | FM radio |
| USB | Type-C 1.0 reversible connector |
| Sensors | Fingerprint (rear-mounted), accelerometer, proximity, compass |
| Battery | Non-removable Li-Ion 3990 mAh battery |
| Colors | Black |
